Cortadora de plasma de arco piloto sin contacto bestarc BTC500DP 7GEN 50A
2 Year Warranty
Comprados juntos frecuentemente
| Model | BTC500DP 7GEN | ||
|---|---|---|---|
| 220V | 110/220V | ||
| Power Supply / Phases (V-Ph) | 220V ±15% | 110V ±10% | 220V ±15% |
| Duty Cycle @ 78°F (25°C) | 60% | 60% | |
| Rated Power (KVA) | 6.3 | 4.2 | 6.3 |
| Input Current Range (A) | 12 - 29 | 20 - 38.5 | 12 - 29 |
| Output Current Range (A) | 15 - 50 | 15 - 35 | 15 - 50 |
| Rated Output Voltage (V) | 100 | 94 | 100 |
| No-Load Voltage (Open Circuit)(V) | 260 | 260 | |
| Efficiency (%) | 60 | 60 | |
| Insulation Class | F | F | |
| Protection Class | IP21S | IP21S | |
| Plasma Arc Starting | Non - Touch | Non - Touch | |
| Air Flow Pressure Range (PSI) | 40-65psi | 40-65psi | |
| Air Flow Rate (CFM) | 150L/min | 150L/min | |
| Clean Cutting Thickness (mm) | 12mm | 10mm | 12mm |
| Cutting Thickness Severance (mm) | 16mm@65psi | 12mm@65psi | 16mm@65psi |
| Cutting Speed 10mm | 200mm/min@65psi | 150mm/min@65psi | 200mm/min@65psi |
| Machine Dimensions (mm) | 377x164 x264mm | 377x164 x264mm | |
| Shipping Weight (kgs) | 6.1kgs | 6.1kgs | |
🛡️3-Year Warranty
All Bestarc machines are covered by a 3-year warranty.
Best in the price range
Great product, great service.
Well I haven’t had it very long and only used it twice to check things out but from what I’ve seen, it’s going to be a great addition to my workshop. Very easy to set up and use. Amazingy clean cuts in metal as thick as 1/2 inch. The 120 power volt option makes it usable anywhere there’s compressed air. All at a very affordable price!
A készülék teljesen megfelel az igenyeimnek, az ár érték aránya egyedülálló.
A webáruház jól átlátható, jó termékinformációkat, adnak, gyorsan mrgérkezett a rendelés.
Csak ajánlani tudom mindenkinek, mind a készüléket, mind a boltot!👌👍😁
I have only use this plasma cutter for a short time. It’s so small and light. Having the regulator built-in is great.
Its build quality is good.
Service was good from Bestarc. I went direct to the Bedtarc store for a good price with free delivery.
BTC500DP 7GEN Video Review
